Hdmi 18g To DisplayPort 1.2 Converter
| Introduction | |
|---|---|
| Converts an HDMI input into a DisplayPort signal_x000D_ Supports resolutions up to 3840x2160@60Hz_x000D_ Supports 7.1 channel surround audio_x000D_ Quick and simple Plug & Play installation_x000D_ 2 year warranty_x000D_ _x000D_ A converter allows devices which use different interfaces e.g. HDMI and DisplayPort to connect to one another by converting one signal to the other._x000D_ _x000D_ The Lindy HDMI 18G to DisplayPort 1.2 Converter allows the connection of HDMI source devices, such as a PC, Blu-ray player or media player to DisplayPort monitors digital signage and LFDs (Large Format Displays). Supporting resolutions up to 3840x2160@60Hz 4:4:4 8bit or 2560x1440@120Hz, this converter ensures superior clarity content within innovative workspaces, engaging collaboration environments and educational setups. Immersive multi-channel audio is supported up to 7.1CH to compliment the video on screen._x000D_ _x000D_ The converter can also be used to add another display to extend the available desktop workspace and increase productivity. It is also ideally suited for travelling due to its compact, lightweight form factor and convenient Plug & Play installation._x000D_ _x000D_ |
|
| Technical details | |
| Compliance certificates | CE, REACH, RoHS |
| Harmonized System (HS) code | 84733080 |
| Features | |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Power source | DC |
| Cable length | 0.095 m |
| Connector 1 | HDMI Type A (Standard) |
| Connector 2 | DisplayPort |
| Connector 1 gender | Female |
| Connector 2 gender | Male |
| HDMI version | 2.0 |
| HDCP | Y |
| HDCP version | 1.4 |
| DisplayPort version | 1.2 |
| High Dynamic Range (HDR) supported | Y |
| Maximum resolution | 3840 x 2160 pixels |
| Data transfer rate | 18 Gbit/s |
| Bandwidth | 21600 MB/s |
| Product colour | White |
| Chipset | LT6711A |
| Jacket material | Acrylonitrile butadiene styrene (ABS) |
| Supported audio channels | 7.1 |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 85 °C |
| Storage temperature (T-T) | -20 - 85 °C |
| Operating relative humidity (H-H) | 20 - 95% |
| Sustainability | |
| Sustainability certificates | CE, REACH, RoHS |
| Weight & dimensions | |
| Weight | 25 g |
| Width | 20.5 mm |
| Depth | 16.5 mm |
| Height | 3.5 mm |
| Packaging data | |
| Package width | 174 mm |
| Package depth | 20 mm |
| Package height | 194 mm |
| Package type | Polybag |
| Package weight | 30 g |
