TRIPP LITE Waterproof Electrical Junction Box - Surface Mount, Industrial, Single Gang, IP67, TAA, 2 Cutouts
Brand:
EATON CORPORATION
Part Number:
N206-SB01-IND
Stock:
£8.83
(Excl VAT)
£10.59
(incl. VAT)
| Introduction | |
|---|---|
| Waterproof Electrical Junction Box Recommended for Outdoor or Harsh Outdoor Environments This surface-mount junction box is ideal for connecting Cat5e/6 networks, USB 3.0 or 4K HDMI installations in outdoor applications and other areas where protection from harsh elements is essential. It is constructed with a high-impact polycarbonate (UL94V-0) housing and flexible rubber gaskets. Two knockout holes are suitable for standard M16 cable glands (included) or M32 conduit glands. Wall-mounting hardware is included. Designed for Use with Tripp Lite Industrial-Grade Cables and Couplers The industrial junction box with two bulkhead cutouts works with Tripp Lite's N206-Series industrial Cat5e/6 patch cables and N206-BC01-IND bulkhead coupler or N206-KJ01-IND keystone jack, the U325-Series industrial USB 3.0 cables and U325-000-IND bulkhead coupler and P569-000-FF-IND bulkhead coupler and P569-Series industrial 4K HDMI cables (all sold separately). IP68 Rating Denotes Resistance to Dust and Water The IP68 rating means the junction box is not only 100% protected against dust, but also able to endure immersion in 1.5 meters of water for up to 60 minutes with no damage or decline in performance, making the box ideal for basement applications.* *Based on manufacturer's guarantee. Standard IP68 rating guarantees water resistance at depths up to 1.5 meters for up to 30 minutes. TAA-Compliant for GSA Schedule Purchases The N206-SB01-IND is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts. Lifetime Warranty The N206-SB01-IND is backed by a lifetime warranty, ensuring reliability and performance. |
|
| Features | |
| Product colour | White |
| International Protection (IP) code | IP67 |
| Number of screws | 8 |
| Certification | TAA, RoHS |
| Packaging data | |
| Package width | 203.2 mm |
| Package depth | 12.7 mm |
| Package height | 271.8 mm |
| Package weight | 230 g |
| Technical details | |
| Master (outer) case GTIN (EAN/UPC) | 10037332206210 |
| Logistics data | |
| Products per master (outer) case | 5 pc(s) |
| Master (outer) case width | 406.4 mm |
| Master (outer) case length | 25.4 mm |
| Master (outer) case height | 508 mm |
| Master (outer) case gross weight | 1.09 kg |
| Country of origin | Taiwan |
