Catalyst 2960l 24 Port Gige With Poe 4 X 1g Sfp Lan Lite
Brand:
CISCO
Part Number:
WS-C2960L-24PS-LL
Stock:
£1,842.33
(Excl VAT)
£2,210.80
(incl. VAT)
| Introduction | |
|---|---|
| Cisco Catalyst 2960-L Series Switches pack PoE+ and basic Layer 2 features in to a slim and fan-less body, bringing flexibility and reducing cables for places, such as retail outlets and office branches, that have confined space or out-of-wiring closet requirements. The 2960-L Series is ideally suited for hotels or school buildings with less than 50 users on a floor, providing 802.1X authentication to access points. Designed for operational simplicity to lower TCO, the 2960-L Series enables energy-efficient business operation, allows zero-touch deployment across WAN, and features web user interface for management simplicity. - Layer 2 - 24-Ports + 4 Gigabit SFP uplinks |
|
| Management features | |
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Y |
| ARP inspection | Y |
| MIB support | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 4 |
| Console port | RJ-45 |
| Network | |
| Networking standards | IEEE 802.1D,IEEE 802.1ab,IEEE 802.1af,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
| Full duplex | Y |
| Broadcast storm control | Y |
| Auto MDI/MDI-X | Y |
| Spanning tree protocol | Y |
| VLAN support | Y |
| Virtual LAN features | Private VLAN |
| Number of VLANs | 4094 |
| Data transmission | |
| Switching capacity | 56 Gbit/s |
| MAC address table | 16000 entries |
| Jumbo frames support | Y |
| Security | |
| DHCP features | DHCP server,DHCP client |
| Access Control List (ACL) | Y |
| IGMP snooping | Y |
| Security algorithms | SNMP,SSH |
| SSH/SSL support | Y |
| Multicast features | |
| Multicast support | Y |
| Protocols | |
| Management protocols | SNMPv3, Telnet, RMON |
| Design | |
| Rack mounting | Y |
| Form factor | 1U |
| Product colour | Grey |
| LED indicators | Activity, Link, PoE, Speed, System |
| Safety | UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1 |
| Electromagnetic compatibility | 47CFR Part 15 (CFR 47) Class A, AS/NZS CISPR22 Class A, CISPR22 Class A, EN55022 Class A, ICES003 Class A, VCCI Class A, EN61000-3-2, EN61000-3-3, KN22 Class A, CNS13438 Class A |
| Performance | |
| Built-in processor | Y |
| Processor frequency | 800 MHz |
| Internal memory | 512 MB |
| Flash memory | 256 MB |
| Mean time between failures (MTBF) | 909838 h |
| Power | |
| AC input voltage | 110 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 0.26 A |
| Power consumption (typical) | 32.9 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Total Power over Ethernet (PoE) budget | 195 W |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 40 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 4500 m |
| Weight & dimensions | |
| Width | 445 mm |
| Depth | 265 mm |
| Height | 44 mm |
